Acoustical data
- Max SPL : 91dBSPL @ 1m
- Sensitivity : 84dB/1W @ 1m
- Range ±3dB : 3.2m
- Range ±5dB : 5m
- Frequency bandwidth : (-10dB) 120Hz-18kHz
- Horizontal opening angle : ±100° (1kHz) / ±70° (4kHz)
- Vertical directivity : Wavefront synthesis
Electrical data
- Continous power : 30W
- Nominal impedance : 6Ω
- Connectors : Ceramic terminal block screw
- Protection : Thermal fuse
- Certification : EN54-24 certified
Mechanical data
- Dimensions (WxPxH) : 128mm x 117mm x 192mm
- Net / shipping weight : 2kg / 2.7kg
- Environment : IP54 (25° - 55°)
- Colors : white, black
