Acoustical data
- Max SPL : 94.5dBSPL @ 16m
- Sensitivity : 71dB/1W @ 16m
- Range ±3dB : 31m
- Range ±5dB : 42m
- Frequency bandwidth : (-10dB) 120Hz-18kHz
- Horizontal opening angle : ±100° (1kHz) / ±70° (4kHz)
- Vertical directivity : Wavefront synthesis
Electrical data
- Continous power : 300W
- Nominal impedance : 8Ω
- Connectors : Ceramic terminal block screw
- Protection : Thermal fuse
- Certification : EN54-24 certified
Mechanical data
- Dimensions (WxPxH) : 128mm x 117mm x 1977mm
- Net / shipping weight : 16.2kg / 17.8kg
- Environment : IP54 (25° - 55°)
- Colors : white, black
