Acoustical data
- Max SPL : 92dBSPL @ 8m
- Sensitivity : 72dB/1W @ 8m
- Range ±3dB : 15m
- Range ±5dB : 20m
- Frequency bandwidth : (-10dB) 120Hz-18kHz
- Horizontal opening angle : ±100° (1kHz) / ±70° (4kHz)
- Vertical directivity : Wavefront synthesis
Electrical data
- Continous power : 150W
- Nominal impedance : 8Ω
- Connectors : Ceramic terminal block screw
- Protection : Thermal fuse
- Certification : EN54-24 certified
Mechanical data
- Dimensions (WxPxH) : 128mm x 117mm x 1026mm
- Net / shipping weight : 8.3kg / 9.1kg
- Environment : IP54 (25° - 55°)
-
Colors : white, black
